Features
- PERMEX® synthetic rubber diaphragm with dual filtered fixed bypass
- ADA compliant metal oscillating non-hold-open handle with triple seal handle packing
- ¾” I.P.S. wheel handle Bak-Chek® angle stop
- Adjustable tailpiece
- High back pressure vacuum breaker
- Spud coupling for ¾” concealed back spud urinals
- Sweat solder adapter
- Elbow flush connection
- Exposed parts chrome plated
- High copper, low zinc brass castings for dezincification resistance
- Non-hold-open handle, fixed metering bypass and no external volume adjustment to ensure water conservation
- Flush accuracy controlled by CID technology
- Diaphragm, handle packing, stop seat and vacuum breaker to be molded from PERMEX® rubber compound for chloramine resistance
| Brand | Sloan® |
| Sub-Brand | Royal® |
| Case LxWxH | x x |
| Color | Rough Brass |
| Cube | 0 |
| UPC | 671254279179 |
| Packaging Put/Up | 1/ea |
| Pallet Ti x Hi = Qty | x = |
| Sell UOM LxWxH | EA - x x |
| Sell UOM Weight (lbs.) | 6.653 |
| Weight | 6.653 |
Safety Data Sheets
No Safety Data Sheets available for this product.
Technical Resources
| Name | Download | File type | |
|---|---|---|---|
|
|
Spec Sheet | 255 KB |
