Product Overview
The Sloan Royal® 3911544 Manual Concealed Flushometer delivers reliable, water-efficient flushing performance for commercial water closet installations. Designed for a 3.5 gallons-per-flush cycle, this concealed manual flushometer features a semi-red brass diaphragm valve and rugged construction for corrosion resistance and long service life. An ADA-compliant non-hold-open oscillating handle and CID™ precision water control ensure consistent flush accuracy while preventing excessive water use. With features like an adjustable tailpiece, vandal-resistant stop cap, and 1″ IPS inlet, this flushometer is ideal for demanding high-traffic restrooms in schools, offices, and public facilities. Built to industry standards and certified for quality and performance, it’s a dependable choice for water conservation and commercial restroom efficiency.
Features
- Details:Flush Volume: 3.5 gpf (13.2 lpf)Finish: Rough Brass (RB)Valve: DiaphragmValve Body Material: Semi-red BrassFixture Type: Service SinkFixture Connection: Not IncludedSupply Pipe: 1” (25mm)L Dimension: 6.75” (171mm) (6-3/4-LDIM)Handle Type: Metal Oscillating (J)Vacuum Breaker: Less (XYV)
- Water conservation is aided by the ADA-compliant, non-hold open handle, which prevents toilet from exceeding intended flush volume
- Flush accuracy is controlled by CID™ technology, also enhancing water efficiency
- Integrity of the product is maintained with the vandal-resistant stop cap
- Durability is facilitated with high copper, low zinc brass castings for dezincification resistance
- Adjustable tailpiece
- PERMEX® synthetic rubber diaphragm with dual filtered fixed bypass
- Valve body, cover, tailpiece and control stop shall be in compliance with ASTM alloy classification for semi-red brass
- Valve shall be in compliance to the applicable sections of ASSE 1037
| Brand | Sloan® |
| Sub-Brand | Royal® |
| Case LxWxH | x x |
| Color | Rough Brass |
| Cube | 0 |
| UPC | 671254230491 |
| Packaging Put/Up | 1/ea |
| Pallet Ti x Hi x Qty | x x |
| Sell UOM LxWxH | EA - x x |
| Sell UOM Weight (lbs.) | 7.22 |
| Weight | 7.22 |
Safety Data Sheets
No Safety Data Sheets available for this product.
Technical Resources
| Name | Download | File type | |
|---|---|---|---|
|
|
Spec Sheet | 359 KB |
