- Sloan Royal 995-0.5 2-10 3/4 LDIM (3915513) Concealed Flush
You are not logged in
Please log in to continue or proceed as a guest.
Product Overview
The Sloan Royal® (3915513) 995-0.5-RB Manual Concealed Urinal Flushometer combines water conservation, durability, and commercial-grade performance. Engineered for rear spud urinals, this hydraulic diaphragm flushometer delivers a low 0.5 gallons-per-flush rate (1.9 Lpf) to help reduce water usage while maintaining effective flush power. Built with semi-red brass and a PERMEX® synthetic rubber diaphragm with dual filtered fixed bypass, it provides long service life and chloramine resistance. Compatible with a range of remotely positioned push-button actuators and featuring an ADA-compliant non-hold-open configuration plus vandal-resistant stop cap, it’s ideal for schools, offices, and retail restrooms. Meets key certifications including ADA, cUPC Green, LEED water efficiency credits, and more.
Features
- Details:Flush Volume: 0.5 gpf (1.9 lpf)Finish: Rough Brass (RB)Valve: DiaphragmValve Body Material: Semi-red BrassFixture Type: UrinalFixture Connection: Rear SpudRough-in Dimension: 13.5” (343mm)Spud Coupling: 0.75” (19mm)Supply Pipe: 0.75” (19mm)L Dimension: 2”-10.75” (51-273mm)
- Water conservation is aided by the ADA-compliant, non-hold open actuator, vandal-resistant stop cap to facilitate security
- Made from rough brass
- PERMEX® synthetic rubber diaphragm with dual filtered fixed bypass
- Valve body, cover, tailpiece and control stop shall be in compliance with ASTM alloy classification for semi-red brass
- Valve shall be in compliance to the applicable sections of ASSE 1037
| Brand | Sloan® |
| Sub-Brand | Royal® |
| Case LxWxH | x x |
| Color | Rough Brass |
| Cube | 0 |
| UPC | 671254203884 |
| Packaging Put/Up | 1/ea |
| Pallet Ti x Hi x Qty | x x |
| Sell UOM LxWxH | EA - x x |
| Sell UOM Weight (lbs.) | 8.058 |
| Weight | 0 |
Safety Data Sheets
No Safety Data Sheets available for this product.
Technical Resources
| Name | Download | File type | |
|---|---|---|---|
|
|
Spec Sheet | 532 KB |
